22.31 Ft Roll Up Door Refrigerated Truck Bodies

Product Details

Place of Origin: China

Brand Name: GET VEHICLES

Certification: ISO 9001/TS16949

Model Number: GET.6XLC./22

Payment & Shipping Terms

Minimum Order Quantity: 2 units

Price: USD 80-100 /Sqm

Packaging Details: SKD Frame box package/CBU Container Package

Delivery Time: 10 working days

Payment Terms: T/T, L/C

Supply Ability: 1000 Sqm/month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                22.31 Ft Refrigerated Truck Bodies, ISO 9001 Refrigerated Truck Bodies


Product Name:	6800x2600x2660 Refrigerated Insulated Truck Box With FRP PU Sandwich Panels	Box Application:	Insulated Trucks/expedition Box/RV
Skin Material:	FRP / FiberGlass Composite Material	Truck Body Core Material:	PUR -Polyurethanes
Truck Body Portal:	Stainless Steel Mirror Surface	Truck Body Rear Door:	2-wings Opening Hinge Doors
Amount Chassis:	ISUZU/Toyota/ FOTON/Ford/JAC	Quick Installation:	Glue Fast Installation 3 People 1.5 Hour / Unit
Truck Body Shipment:	SKD/CKD /CBU	Truck Body Working Life:	10-15 Years Per The Working Condition

Product Name:	6800x2600x2660 Refrigerated Insulated Truck Box With FRP PU Sandwich Panels
Box Application:	Insulated Trucks/expedition Box/RV
Skin Material:	FRP / FiberGlass Composite Material
Truck Body Core Material:	PUR -Polyurethanes
Truck Body Portal:	Stainless Steel Mirror Surface
Truck Body Rear Door:	2-wings Opening Hinge Doors
Amount Chassis:	ISUZU/Toyota/ FOTON/Ford/JAC
Quick Installation:	Glue Fast Installation 3 People 1.5 Hour / Unit
Truck Body Shipment:	SKD/CKD /CBU
Truck Body Working Life:	10-15 Years Per The Working Condition

Product Description

6800x2600x2660 Roll Up door Refrigerated Truck Bodies

Refrigerated Truck Bodies Key Features:

Reefer container semitrailers are mobile and flexible.A refrigerated container is placed on top of a semi, flat container or frame truck. Refrigerated containers are usually equipped with separate refrigeration equipment.It is currently the most common refrigerated semi trailer.Compared with the van refrigerated semi trailer, this refrigerated semi trailer has more advantages in price, and the refrigerated container is detachable, with high mobility and flexibility.But because of the independent frame, the weight utilization coefficient of the whole vehicle is not as good as the former.At the same time, this model needs to be attached to the company to obtain the operation certificate.

K .Value for the Truck Body Box		0.295 W/㎡ ℃
Max. Overall Length	22.31 ft	6,800 mm	0~14750mm can choose
Max. Overall Width	8.53 ft	2,600 mm	0~ 3200 mm can choose
Max. Overall Height	8.53 ft	2,600 mm	0~3200 mm can choose
Max. Floor Thinckness	4 .13 inch	105 mm	45-105mm can choose
Side Wall Thickness	3 .31 inch	84 mm	45-105mm can choose
Front Wall Thickness	3 .31 inch	84 mm	45-105mm can choose
Rear Door Panel	3 .31 inch	84 mm	45-105mm can choose
Roof Wall	4 .13 inch	105 mm	45-105mm can choose

Truck Body Side or Specail Door Options

22.31 Ft Roll Up Door Refrigerated Truck Bodies 0

22.31 Ft Roll Up Door Refrigerated Truck Bodies 1
