Carbon Steel Concrete Mixer Tanker Body For Concrete Mixing Transport Trucks

Name: Carbon Steel Concrete Mixer Tanker Body For Concrete Mixing Transport Trucks
Brand: GENERAL EAST CO.,LTD
SKU: Tankbody
Price: 476.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: GET

Certification: ISO 9001/TS16949

Model Number: Tankbody

Payment & Shipping Terms

Minimum Order Quantity: 2 units

Packaging Details: packed in nude

Delivery Time: 45 working days

Payment Terms: T/T, L/C

Supply Ability: 10 units per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                special purpose vehicle, special use trucks


Material:	Carbon Steel Q345/Q235	Tanker Volume:	8,10,12,000L
Axle No.:	0	Transport Liqulid:	Concrete
Color:	Customized	Tanker Shape:	Round

Material:	Carbon Steel Q345/Q235
Tanker Volume:	8,10,12,000L
Axle No.:	0
Transport Liqulid:	Concrete
Color:	Customized
Tanker Shape:	Round

Product Description

Concrete Mixer Tanker body for concrete mixer truck DIY refit

concrete mixer Special concrete transport trucks (in-transit mixers) are made to mix concrete and transport it to the construction site. They can be charged with dry materials and water, with the mixing occurring during transport. They can also be loaded from a "central mix" plant; with this process the material has already been mixed prior to loading. The concrete mixing transport truck maintains the material's liquid state through agitation, or turning of the drum, until delivery. The interior of the drum on a concrete mixing truck is fitted with a spiral blade. In one rotational direction, the concrete is pushed deeper into the drum. This is the direction the drum is rotated while the concrete is being transported to the building site. This is known as "charging" the mixer. When the drum rotates in the other direction, the Archimedes' screw-type arrangement "discharges", or forces the concrete out of the drum. From there it may go onto chutes to guide the viscous concrete directly to the job site. If the truck cannot get close enough to the site to use the chutes, the concrete may be discharged into a concrete pump, connected to a flexible hose, or onto a conveyor belt which can be extended some distance (typically ten or more metres)

Concrete Mixer Tanker body for concrete mixer truck DIY refit
volume type		Refitting Equipments
		Reducer		Pump			Motor
		Brand	Model	Brand	Model	Displancement	Brand	Model	Displancement
9cbm	Standard	ZF	P4300	DANFOSS	T90PV075	75cc	DANFOSS	T90MF75	75cc
	options 1	PMP	PMB6.5SP	DANFOSS	T90PV075	75cc	DANFOSS	T90MF75	75cc
	option 2	ZF	CML8	DANFOSS	T90PV075	75cc	DANFOSS	**
	Option 3	DANFOSS	PMG61.2new	DANFOSS	T90PV075	75cc	DANFOSS	T90MF75	75cc
	options 4	ZF	P4300	EATON	5423-518		EATON	5433-138	88cc
10cbm	Standard	ZF	P5300	DANFOSS	T90PV075	75cc	DANFOSS	T90MF75	75cc
	options 1	DANFOSS	PMG61.2new	DANFOSS	T90PV075	75cc	DANFOSS	T90MF75	75cc
	option 2	ZF	P4300	DANFOSS	T90PV075	76cc	DANFOSS	T90MF75	75cc
	Option 3	PMP	PMB6.5SP	DANFOSS	T90PV075	77cc	DANFOSS	T90MF75	75cc
	options 4	ZF	CML8	DANFOSS	T90PV100	100cc	**	**
12cbm	Standard	ZF	P5300	DANFOSS	T90PV100	100cc	DANFOSS	T90MF100	100cc
	options 1	DANFOSS	PMG61.2 new	DANFOSS	T90PV100	100cc	DANFOSS	T90MF100	100cc
	option 2	DANFOSS	PMG71.2	DANFOSS	T90PV100	100cc	DANFOSS	T90MF100	100cc
	Option 3	PMP	PMB7.1SP	DANFOSS	T90PV100	100cc	DANFOSS	T90MF100	100cc
	options 4	ZF	CML10	DANFOSS	T90PV100	100cc	**	**
1,Water Tank 600L Steel Material-pneumatic, Option: Fiber Glass Tank-Electrical Power USD 600 /set
2,Water Gun is Chinese Brand
3,Cololer: 6~12cbm with YS-18L
4,Options: Constant Speed Electrical Control System: Usd 17000/set,Have to confirm the chassis before producing.
